Total Station Autocollimator
- An upgraded device based on our already mature technology for testing and adjusting fully integrated systems including mechanics, optics, and lasers.
- Emerging optomechatronics AR/VR industry has introduced special applications requirement:
- Interalignment and testing of lasers, optics, mechanics and electronic sensors
- Angular accurate optical measurements with resolution of 0.01 arc sec or better.
- Implementing fusion of several wavelengths including NIR into one system.
- Measurements from remote mechanical dimensions.
- Centering & Alignment
- Measurements of multi laser array such as VCSEL in respect with other optical sensors.
- Our Total Station Autocollimator does it all and much more, including projection of virtual objects from user defined distance.
Specifications
Autocollimation
| Parameters | Value |
|---|---|
| FoV Autocollimator | ±60’ (H) x ± 40’ (V) |
| FoV Beam Profiler | ±120’ (H) x ± 80’ (V) |
| Clear Aperture | 36 mm |
| Autocollimator’s Resolution | 0.005 sec |
| Autocollimator’s Accuracy | 1.0 sec |
| Light Source | -Switchable RG/IR -Switchable RGB -Special order: 1060 nm |
| Line of Sight Retention as Function of Focusing | ±2.5 seconds |
| Focusing Distance | Calibrated from 18 cm to infinity |
| Built in coarse aiming Laser Pointer | 650 nm power <1.0 mW Class 2 laser product, IEC60825-1 |
| Spectral Response | 350 – 1310 nm (Telescope Mode) |
| Resolution (H x V pixels) | 8200 x 5600 |
| Gain Control | x400 |
| Exposure Speed | 39 µsec to 2 sec |
| Frame Rate | 50 fps, a few hundreds on ROI mode |
| Pixel Size | 2.3 µm x 2.3 µm (binning 1) |
| Pixel Bit Depth | 8/16 bits |
| Background Subtraction | User activated |
| Trigger | Internal Software |
| Interface | USB 3.0, Windows 8/10/11 (32 & 64 bit) |
Beam Analysis – Collimated Laser Beams Input
Parallel Multi-Beam divergence & power measurement (Default – 400 max.)
| Parameters | Value |
|---|---|
| Max. Laser Beam Input Orientation | ±50’ (H) x ± 40’ (V) ±14 mrad (H) x ± 11 mrad (V) |
| Laser Beam Divergence Measurement | Down to 0.05 mrad |
| Resolution of Beam Divergence | Better than ±1 µrad Position ±0.5 µrad |
| Multiple Beams Measurement in Parallel | Standard – up to 400. |
| Fast Mode Measurement | Up to 1,000 fps for partial ROI |
General Measurements
Straightness measurement – up to 2.5 meters
Remote Lateral Mechanical Measurements – microns accuracy
Testing of optical elements, including roll angle
Image Projection & Focusing
Target projection for optical systems from 2.5 meters to infinity
Motorized Focusing from 0.18 meters to infinity
Straightness Measurement
| Parameters | Value |
|---|---|
| Lateral Measurement on Object Plane | With micron accuracy dependent on object distance |
| Virtual Object Creation* | -2.5 [m] to -Infinity |
| Cooperative Cross Target | Automatic display of lateral deviation along -2.5 [m] to -Infinity |
The application program is compatible with Windows 8/10/11 OS (32 & 64 bit). For custom integration, an SDK package software is offered as standard.
Ordering Information
EAC-1012-19-FO-E/T: Complete system including a collimator unit with USB3.0 camera, focusing mechanism, software on Flash Drive and a retro-reflector for infinity adjustment.
See available models.
EAC-1012-19-FO-E/T-RG-IR: Autofocusing EAC, with Red, Green or IR – Switchable (default – Red IR 850 nm)
EAC-1012-19-FO-E/T-RGB: Autofocusing EAC, with Red, Green, Blue – Switchable
EAC-1012-19-FO-E/T-1060*: Autofocusing EAC, with LED 1060 nm
*Special Order Version
EAC-1012-19-RHO: Attachment for initial alignment based on rhomboid optics.
EAC-1012-19-STG: Optional Accessory – Pan/Tilt Stage.
EAC-1012-19-FW5: Optional Accessory providing a 36 [mm] clear aperture filter wheel for ND Filters, Polarization Filters and others.
* Typical Application – Adjustment of projected laser beam to certain distance as dictated by the virtual image setting
